EC Drive Sliding Door Operator



1.
General System Description

The EC Drive sliding door operator is able to move doors up to 120 kg leaf weight and the system is uncompromisingly reliable in all details. High-quality material and the latest actuation technology guarantee a premium performance. Owing to the small abrasion and the self-cleaning roller carriage the system operates extremely quiet.

2.
Features

EC Drive siding door operator features

  •  Control Panel: Microprocessor control panel with the latest technology to give the most flexible application according to the demand of the client.
  • Main Switch: Digital program switch with self learning mode and five different operating functions; automatic, OFF, Permanent open, Partial Open, Exit Only.
  • Safety Photocells:
    Sensors: Microwave detection radars to be installed outside and inside with adjustable range for detection and weather mode option.
3.
Technical Data

EC Drive sliding door operator technical data

  • Maximum Leaf Weight, Single-leaf : 120 Kg.
  • Maximum Leaf Weight, Double-leaf : 2 x 120 Kg.
  • Maximum Opening Speed, Double-leaf : 0.7 m/s.
  • Maximum Closing Speed : 0.5 m/s.
  • Leaf height: up to approx. 3000 mm.
  • Opening Width: up to approx. 3000 mm.
  • Material of Door Leaf: Glass, Aluminum, Wood, PVC or Steel.
  • Detection Range of Radar: from 0.5 m to 4.5 m.
4.
Standard and Optional Accessories

EC Drive siding door operator accessories

  • Electric Lock
  • Key Switch
  • Magic Switch
  • Battery back-up system for 2 hours
